Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X100SU
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Single-Acting Aluminum Mini Cylinder MTBL20X100SU Specifications
- Model: MTBL20X100SU
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 100mm
- Operation: Air to port 1 (Port 2 auto-return via spring)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable cushion at both ends
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Mounting: Standard side/face mounting holes (M4x0.7)
- Weight: 350g ±5%
- Dimensions (L×W×H): 195mm × 34mm × 34mm (full extension)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (Grease-free operation available)
Ultra-compact cylinder optimized for space-constrained automation systems. Features corrosion-resistant construction with precision honed tube (≤Ra0.4μm) and low friction design (≤0.15 dynamic friction coefficient). Requires 5μm filtered dry air (ISO8573-1 class 3). Includes anti-rotation guide for precise linear motion.
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Food packaging machine grippers
- Semiconductor wafer positioning systems
- Automated optical inspection (AOI) equipment
Installation note:
Max lateral load ≤3N. For vertical mounting, use speed controller (ASC-06)
to prevent piston rod buckling. Alignment tolerance: ±0.5° angular misalignment.
| Property | Property Value |
|---|---|
| sku | MTBL20X100SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
