Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X10U
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Series Single-Acting Aluminum Miniature Cylinder MTBL20X10U
- Model: MTBL20X10U
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Cushioning: Adjustable rubber bumper
- Mounting type: Through-hole (4.5mm x 2) with 30mm center distance
- Seal material: NBR (Nitrile rubber)
- Max piston speed: 500 mm/s
- Weight: 0.25 kg (cylinder body only)
- Dimensions (LxWxH): 70mm x 30mm x 20mm (excludes rod extension)
- Rod thread: M5x0.8 external thread
- Rod end: Standard spherical plain bearing
- Corrosion resistance: Anodized aluminum body
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features a 20mm precision-bored barrel with chrome-plated piston rod (hardness HRC 45-50). The lightweight design (250g) reduces inertial load while maintaining 15N theoretical thrust at 0.6MPa. Requires 40μm filtered compressed air with ISO VG32 lubricant for optimal performance.
- PCB handling robots in electronics manufacturing
- Medical device actuation mechanisms
- Packaging machine gripper positioning
- Laboratory sample sorting systems
- Automated camera lens adjustment modules
Installation guidelines:
Mount using Class 4.8 or higher grade fasteners. Maintain 0.5-1mm clearance between rod end and load during alignment. For vertical installations exceeding 45° angle, specify optional spring-loaded rod lock (MTBL-LK accessory).
| Property | Property Value |
|---|---|
| sku | MTBL20X10U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
