Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X15SCA
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Series Single-Acting Aluminum Miniature Cylinder MTBL20X15SCA
- Model: MTBL20X15SCA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 15mm (adjustable cushioning)
- Operation: Air pressure extension / Spring retraction
- Material: Aluminum alloy body, stainless steel piston rod
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃ (ambient & medium)
- Port size: M5x0.8 (standard) with NPT1/8 adapter optional
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting: Basic type (no built-in mounts) with 3x ø4.5mm through holes
- Piston rod thread: M6x1.0 external thread
- Protection rating: IP54 (standard seals)
- Weight: 180g ±5% (excluding accessories)
- Dimensions:
- Length: 101mm (fully retracted)
- Width: 32mm (cylinder body diameter)
- Height: 32mm (including mounting flange)
Ultra-compact pneumatic actuator optimized for space-constrained automation systems. Features precision-machined aluminum construction with hard anodized surface treatment for wear resistance. The dual-purpose cushioning system minimizes end-impact noise while allowing stroke adjustment. Requires dry/lubricated air (ISO8573-1 class 3.4.2).
- PCB handling robots in electronics assembly
- Dispenser valve actuation in medical devices
- Precision clamping mechanisms for CNC tooling
- Label applicators in packaging lines
- Optical component positioning systems
Installation tip:
Lubricate piston rod weekly with ISO VG32 hydraulic oil. For vertical mounting,
ensure spring chamber faces downward to prevent moisture accumulation.
Maximum side load: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | MTBL20X15SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <15mm> |
