Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X15U
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Series Single-Acting Aluminum Miniature Cylinder MTBL20X15U
- Model: MTBL20X15U
- Type: Single-acting (spring return)
- Bore size: 20mm
- Stroke: 15mm
- Operation: Push operation with spring return
- Material: Aluminum alloy body & end caps
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard)
- Cushioning: Adjustable buffer (both ends)
- Mounting style: Basic type (multiple options available)
- Piston seal: NBR rubber
- Rod material: Stainless steel (SUS304)
- Weight: ~0.25kg (without accessories)
- Dimensions: 100mm(L) × 42mm(W) × 42mm(H) (full extension)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision-machined aluminum construction with double-layer chromated coating for corrosion resistance. The spring-return design ensures fail-safe retraction, while the adjustable cushioning minimizes impact noise. Optional magnetic piston version available for position sensing (suffix /M).
- PCB handling robots in electronics assembly
- Dispenser valve actuation in medical devices
- Compact clamping mechanisms in CNC tool changers
- Paper feed systems in office automation equipment
- Precision positioning in semiconductor manufacturing
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 2N·m.
For vertical mounting, ensure rod-end orientation matches gravity direction.
Recommended maintenance interval: 2,000km stroke distance or annually.
| Property | Property Value |
|---|---|
| sku | MTBL20X15U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <15mm> |
