Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X20SCA
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL20X20SCA Single-Acting Aluminum Miniature Cylinder Specifications
- Model: MTBL20X20SCA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port thread: M5×0.8 (standard), G1/8 optional
- Material: Aluminum alloy body, NBR seals
- Weight: 180g ±5g (excluding accessories)
- Dimensions:
- Length: 107mm (fully extended)
- Width: 34mm (max barrel diameter)
- Height: 34mm (square barrel profile)
- Piston speed: 50–700mm/s
- Lubrication: Pre-lubricated (relubrication interval: 3,000km)
Ultra-compact pneumatic actuator combining lightweight aluminum construction with precision machining. Features a square barrel profile for space-efficient mounting in confined areas. The spring-return mechanism ensures fail-safe retraction with 0.25N return force. Includes dual-position mounting slots (4×M4 threaded holes) for flexible orientation.
- PCB handling robots in electronics assembly
- Precision clamping in micro-machining centers
- Valve actuation in portable medical analyzers
- Paper feed mechanisms in compact printers
- Camera module positioning in inspection systems
Installation note:
For vertical mounting, limit lateral load to ≤5N. Use locknuts (not included) for
vibration-prone applications. Requires 5μm filtered air with ISO VG32 lubricant
for optimal seal life. Allow 2mm clearance around cylinder for heat dissipation.
| Property | Property Value |
|---|---|
| sku | MTBL20X20SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <20mm> |
