Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X20U
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL20X20U Single-Acting Aluminum Miniature Cylinder Specifications
- Model: MTBL20X20U
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 20mm (customizable 5-100mm)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Material: Aluminum alloy body / NBR seals
- Cushioning: Adjustable rubber cushion
- Mounting style: Female thread (M5x0.8 mounting holes)
- Weight: 0.23kg (excluding accessories)
- Dimensions (L×W×H):
- Basic length: 85mm (20mm stroke version)
- Body width: 34mm
- Height with rod: 47mm
- Piston rod diameter: 8mm
Ultra-compact cylinder featuring precision honed aluminum tube and chrome-plated piston rod. The spring-return design provides fail-safe retraction, while the adjustable cushion prevents end-impact noise. Integrated mounting threads enable direct installation in confined spaces. Compatible with ISO 21287 standard accessories.
- PCB handling robots in electronics assembly
- Label applicators in packaging lines
- Micro-punching mechanisms
- Dental chair position adjustment
- Semiconductor wafer clamping
Operation note: Lubricate through air supply (ISO VG32 recommended).
Maximum side load: 3N. For vertical mounting, use stroke-end locking
nut (optional MTBL-MK accessory).
| Property | Property Value |
|---|---|
| sku | MTBL20X20U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <20mm> |
