Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X25SCA
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL20X25SCA Single-Acting Aluminum Mini Cylinder Specifications
- Model: MTBL20X25SCA
- Type: Single-acting spring return (compact series)
- Bore size: 20mm
- Stroke: 25mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port size: M5 (1/8")
- Mounting type: Basic foot mounting (ISO 6432 standard)
- Material: Aluminum alloy body, NBR seals
- Weight: 0.24kg (bare cylinder)
- Dimensions:
- Total length (L): 91mm (at full retraction)
- Body width (W): 32mm
- Height (H): 26mm (excluding mounting hardware)
- Rod thread: M6×1.0
- Max theoretical thrust: 28.3kgf at 0.63MPa
- Lubrication: Pre-lubricated (non-replenishing design)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features corrosion-resistant anodized surface and precision ground piston rod (hard chrome plated). The MTBL series achieves 1 million cycle durability under standard conditions. Requires 5μm filtered air with ISO 8573-1:2010 class 3.4.2 air quality.
- PCB handling robots in electronics manufacturing
- Medical device clamping mechanisms
- Precision valve actuation in analytical instruments
- Compact packaging machine ejectors
- Semiconductor wafer processing equipment
Installation note:
For optimal performance, align cylinder axis within ±2° of perfect parallelism.
When using in vertical orientation, add external braking for stroke-end position holding.
Maximum side load: 3N at piston rod end.
| Property | Property Value |
|---|---|
| sku | MTBL20X25SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
