Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X25U
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL20X25U Single-Acting Aluminum Mini Cylinder Specifications
- Model: MTBL20X25U
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 25mm
- Operating pressure: 0.15–0.8 MPa
- Max theoretical thrust: 63N (at 0.6MPa)
- Ambient temperature: -20℃ to 80℃
- Port thread: M5×0.8
- Cushioning: Rubber buffer
- Material: Aluminum alloy body, NBR seals
- Weight: 0.25kg (without accessories)
- Dimensions: 70mm(L) × 34mm(W) × 34mm(H)
- Piston rod thread: M5×0.8 (external)
- Mounting options: Basic type (no built-in mounts)
- ISO standard: 6432
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features corrosion-resistant anodized surface and integrated cushioning for smooth end-of-stroke deceleration. Requires 40μm filtered compressed air with ISO VG32 lubricant (optional oil-free operation).
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Packaging machine gripper positioning
- Semiconductor wafer processing equipment
- Automated test fixture clamping
Installation note:
Allow minimum 3mm lateral clearance for thermal expansion.
For vertical mounting, use spring-down orientation to prevent
piston rod sagging. Lubricate every 3 million cycles under
normal operating conditions.
| Property | Property Value |
|---|---|
| sku | MTBL20X25U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
