Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X30SCA
$26.02
Regular price
$33.52
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MTBL20X30SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Manufactured to AIRTAC corporate standards with extruded aluminum cylinder barrel;
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
Installation note:
Maximum side load 15N. For vertical mounting, use speed controller to prevent piston overstroke.
Lubricate every 500km travel distance under continuous operation.
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Series Single-Acting Aluminum Miniature Cylinder MTBL20X30SCA Specifications
- Model: MTBL20X30SCA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 30mm (±1.5mm tolerance)
- Operation: Air to port advances piston, spring returns
- Cylinder material: Anodized aluminum alloy (AL6063-T5)
- Piston rod material: Stainless steel (SUS304)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Cushioning: Rubber buffer with adjustable shock absorber
- Port size: M5x0.8 (Dual ports for air inlet)
- Mounting: Standard ISO 6432 mounting slots
- Weight: 210g ±5g (without accessories)
- Dimensions:
- Length: 116mm (full retracted)
- Width: 32mm (including mounting lugs)
- Height: 32mm (square body profile)
- Protection rating: IP54 (standard wiper seal)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision-machined guide rings for smooth operation and anti-rotation design with integrated mounting slots. Requires 5μm filtered air with ISO VG32 lubricant (optional oil-free operation).
Typical Applications:
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Textile machinery thread control
- Semiconductor wafer processing equipment
- Precision clamping in CNC tool changers
Installation note:
Maximum side load 15N. For vertical mounting, use speed controller to prevent piston overstroke.
Lubricate every 500km travel distance under continuous operation.
| Property | Property Value |
|---|---|
| sku | MTBL20X30SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 30mm |
