Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X30U
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Single-Acting Aluminum Miniature Cylinder MTBL20X30U Specifications
- Model: MTBL20X30U
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 30mm
- Operation: Air pressure extension / Spring retraction
- Material: Aluminum alloy body, NBR seals
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Mounting style: Basic type (no built-in mounting)
- Weight: 0.25kg ±5%
- Dimensions:
- Extended length: 95mm
- Retracted length: 65mm
- Body diameter: 32mm
- Rod thread: M6x1.0
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision-machined aluminum construction with anti-corrosion treatment, providing smooth operation at up to 1.5m/s piston speed. Requires 5μm filtered air and monthly lubrication (ISO VG32 recommended).
- PCB handling robots in electronics assembly
- Medical device component positioning
- Food processing equipment actuators
- Semiconductor wafer cassette elevators
- Compact jig clamping mechanisms
Installation tip:
For vertical mounting, use rod-down orientation to prevent moisture accumulation.
Maximum side load capacity: 15N at full extension. Allow 2mm clearance for thermal expansion.
| Property | Property Value |
|---|---|
| sku | MTBL20X30U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 30mm |
