Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X40SCA
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL20X40SCA Single-Acting Aluminum Miniature Cylinder Specifications
- Model: MTBL20X40SCA
- Type: Single-acting spring return (piston type)
- Bore size: 20mm
- Stroke: 40mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Port thread: M5×0.8 (standard) / PT1/8 (optional)
- Body material: Anodized aluminum alloy (A6063)
- Rod material: Stainless steel (SUS304)
- Seal material: Nitrile rubber (NBR)
- Max theoretical thrust: 52.8N @0.5MPa
- Operating speed: 50–800mm/s
- Weight: 0.45kg (approx. including accessories)
- Dimensions: 118mm(L) × 42mm(W) × 42mm(H) (fully retracted)
- Mounting: Standard foot mounting (MF1) with 25mm spacing
- Protection rating: IP54 (standard seals)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if required)
Ultra-compact pneumatic cylinder combining lightweight aluminum construction with precision engineering. Features dual anti-rotation guide slots (4.5mm width) for stable linear motion and an integrated auto switch groove for sensor mounting. The chrome-plated piston rod resists corrosion in humid environments while maintaining smooth operation.
- Compact automation systems in electronics assembly
- Medical device actuation mechanisms
- Precision clamping fixtures for CNC machines
- Textile machinery thread control
- Food processing equipment (non-contact areas)
- Semiconductor handling robots
Installation guidelines:
Maintain ≤0.5mm alignment tolerance during mounting. For vertical installations,
use a 0.5-1.0mm air vent in the upper chamber. Lubricate every 500km of stroke
movement under continuous operation.
| Property | Property Value |
|---|---|
| sku | MTBL20X40SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <40mm> |
