Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X40U
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL Series Single-Acting Aluminum Miniature Cylinder MTBL20X40U
- Model: MTBL20X40U
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 40mm (±1.5mm tolerance)
- Mounting style: Basic type (optional foot/rod flange)
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Cushioning: Rubber buffer (adjustable)
- Seal material: NBR (Nitrile rubber)
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Rod end: Female thread M5×0.8
- Weight: 0.25kg (excluding accessories)
- Dimensions:
- Body length: 72mm
- Extended length: 112mm (72+40mm stroke)
- Width: 34mm (mounting base)
- Height: 34mm (square body profile)
- Protection rating: IP54 (standard seals)
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features anodized surface treatment for corrosion resistance and integrated buffer adjustment. The lightweight design (40% lighter than steel models) reduces moving mass while maintaining 500km minimum service life at rated conditions. Requires 5μm filtered air with ISO 8573-1:2010 class 4 purity.
- PCB handling robots in electronics assembly
- Dispenser actuation in medical devices
- Label application mechanisms in packaging lines
- Precision clamping in optical lens production
- Valve control in analytical instruments
Installation guidelines:
Maximum side load 3N·m. For vertical mounting, use stroke-end locking nut (accessory code LN-5).
Lubricate rod every 500km stroke travel using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | MTBL20X40U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <40mm> |
