Airtac MTBL Single Acting Aluminum Alloy Mini Cylinder MTBL20X50SCA
2. Features riveted aluminum-clad structure for secure connection between end covers and alloy barrel;
3. Utilizes custom bidirectional sealing structure on piston for compact design with integrated oil reservoir functionality;
4. Multiple rear cover configurations enable enhanced installation flexibility;
5. Comprehensive range of cylinder specifications and mounting accessories available for selection.
Category: Aluminum Mini Cylinders | Brand: AIRTAC | Series: MTBL Single-Acting
AirTAC MTBL20X50SCA Single-Acting Aluminum Mini Cylinder Specifications
- Model: MTBL20X50SCA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 50mm (±0.5mm tolerance)
- Operation: Air pressure extension/spring return
- Material: Aluminum alloy body (anodized), CRNA steel piston rod
- Operating pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Weight: 0.45kg (excluding accessories)
- Dimensions: 118mm(L) × 40mm(W) × 40mm(H)
- Seal material: NBR (nitrile rubber)
- Mounting type: Foot-mounted (standard MF1)
- Rod thread: M6x1.0 external thread
- Max speed: 500mm/s
Ultra-compact pneumatic cylinder combining lightweight aluminum construction with precision machining. Features dual air ports for flexible piping configurations and an anti-rotation piston rod design. The corrosion-resistant anodized surface makes it suitable for humid environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- PCB handling robots in electronics assembly
- Dosing valve actuation in medical devices
- Label applicators in packaging lines
- Precision clamping fixtures for CNC tooling
- Ventilation damper control in HVAC systems
Installation tip:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between rod end and load
for optimal cushioning performance. Avoid side load exceeding 2N·m.
| Property | Property Value |
|---|---|
| sku | MTBL20X50SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
