Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X10SCA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Miniature Cylinder MTI10X10SCA Specifications
- Model: MTI10X10SCA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 10mm
- Material: Stainless steel (SUS304 barrel, CR-SUS piston rod)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 120℃
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (standard)
- Mounting style: Basic type (optional flange/clevis kits available)
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65
- Weight: 0.12kg ±5%
- Dimensions (L×W×H):
- Extended length: 70mm (stroke 10mm + body length)
- Retracted length: 60mm
- Barrel diameter: 16mm
- Mounting base: 20mm × 20mm
Ultra-compact stainless steel cylinder designed for precision linear motion in corrosive or washdown environments. Features anti-rust construction with ≤0.01mm repeat positioning accuracy. The spring-return mechanism ensures fail-safe retraction during pressure loss. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Food processing machinery (FDA-compliant environments)
- Medical device actuation systems
- Semiconductor wafer handling robots
- Cleanroom automation with frequent chemical sterilization
- Precision dispensing equipment
Installation guidelines:
Maximum side load ≤3N. For vertical mounting, use rod-end support brackets.
Lubricate with ISO VG32 turbine oil (1 drop/100,000 cycles). Avoid rapid pressure
changes >0.5 MPa/sec to prevent seal damage.
| Property | Property Value |
|---|---|
| sku | MTI10X10SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
