Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X10SU
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI10X10SU Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI10X10SU
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 10mm (customizable up to 50mm)
- Material: SUS304 stainless steel body
- Operating pressure: 0.15–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) or PT1/8 optional
- Cushioning: Adjustable rubber buffer
- Seal material: Fluorocarbon rubber (FKM)
- Weight: 0.12kg (bare cylinder)
- Dimensions: 50mm(L) × 24mm(W) × 24mm(H) (at full retraction)
- Rod thread: M4×0.7 external thread
- Max piston speed: 500mm/s
- Lubrication: Pre-lubricated (DOP-free grease)
- Protection rating: IP65
- Certification: RoHS compliant
Ultra-compact corrosion-resistant cylinder with precision-ground stainless steel barrel, designed for clean environments and space-constrained applications. Features non-rotating piston rod with dual guide bearings for improved alignment. Optional magnetic piston version (MTI10X10SU-M) available for position sensing.
- Pharmaceutical packaging line actuators
- Semiconductor wafer handling systems
- Food processing equipment (NSF-compliant)
- Medical device automation
- Cleanroom robotic arms
- Precision dispensing mechanisms
Installation guidelines:
Use with guided systems to prevent side load. For optimal performance in humid environments,
apply supplemental corrosion inhibitor to exposed rods. Maintain 0.5mm minimum clearance
between magnetic models and sensors. Lubricate every 500,000 cycles with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | MTI10X10SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
