Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X10U
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI10X10U Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI10X10U (Stainless Steel Series)
- Type: Single-acting spring return
- Bore size: 10mm
- Stroke: 10mm (±1mm standard tolerance)
- Operating pressure: 0.05–0.7 MPa
- Max thrust: 4.9N at 0.5MPa
- Port thread: M5×0.8 (standard) or optional G1/8
- Piston speed: 50–700mm/s
- Temperature range: -20℃ to 80℃
- Cushioning: Fixed rubber buffer
- Seal material: NBR (nitrile rubber)
- Weight: 0.15kg (excluding accessories)
- Dimensions (L×W×H):
- Retracted length: 45mm
- Extended length: 55mm
- Body diameter: 16mm
- Mounting base: 20×20mm square flange
Corrosion-resistant mini cylinder with precision-ground stainless steel barrel (SUS304) for harsh environments. Features compact footprint and maintenance-free operation through integrated dust wiper. Requires dry filtered air (40μm+ filtration recommended). Lubricator optional due to pre-lubricated seals.
- Semiconductor wafer handling robots
- Pharmaceutical capsule filling machines
- Food packaging line pusher mechanisms
- Micro-positioning in optical equipment
- Cleanroom automation systems
Installation tip:
Mount using M3 screws (max torque 0.6N·m) with alignment pins.
For vertical installations, add 10% extra pressure to compensate for
spring force. Annual inspection recommended for high-cycle
applications (>500k actuations).
| Property | Property Value |
|---|---|
| sku | MTI10X10U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
