Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X15CA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Miniature Cylinder MTI10X15CA Specifications
- Series: MTI (Stainless Steel Mini Series)
- Bore size: 10mm
- Stroke: 15mm
- Action type: Single-acting (spring return)
- Material: Stainless steel body (SUS304), aluminum alloy end caps
- Operating pressure: 0.05–0.7 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (UNF1/8 adapter optional)
- Piston speed: 50–700 mm/s
- Cushioning: Rubber buffer
- Rod thread: M5x0.8 (external)
- Mounting type: Basic non-switchable
- Seal material: NBR (nitrile rubber)
- Protection rating: IP65
- Weight: 0.12 kg
- Dimensions:
- Total length (retracted): 63mm
- Body diameter: Φ20mm
- Stroke tolerance: ±0.5mm
- Mounting hole spacing: 25mm center-to-center
Corrosion-resistant miniature cylinder with space-saving design, featuring full stainless steel construction for harsh environments. The spring-return mechanism ensures fail-safe retraction with ≤0.5N residual spring force at maximum extension. Optimized for low-friction operation with self-lubricating guide rings. Requires filtered air with 5-40μm filtration and ISO VG32 turbine oil mist lubrication (optional).
- Pharmaceutical packaging machinery
- Food processing equipment actuators
- Semiconductor wafer handling robots
- Laboratory automation positioning
- Cleanroom environment devices
- Precision dispensing systems
Installation note:
Maximum side load 2.5N. For vertical mounting, use rod-down orientation to prevent particle accumulation.
Lubricate every 500,000 cycles in high-cycle applications. Avoid brass fittings to prevent galvanic corrosion.
| Property | Property Value |
|---|---|
| sku | MTI10X15CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
