Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X15SCA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Series Single-Acting Stainless Steel Mini Cylinder MTI10X15SCA Specifications
- Model: MTI10X15SCA
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 15mm (±1mm tolerance)
- Material: Stainless steel body (SUS304) + aluminum end caps
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Fixed rubber buffer
- Mounting style: Threaded (M10x1.25)
- Protection rating: IP40 (standard), IP67 optional
- Weight: 0.15kg ±5%
- Dimensions:
- Total length: 64mm (at retracted position)
- Body diameter: Φ20mm
- Port spacing: 16mm center-to-center
- Rod thread: M4x0.7 external
Ultra-compact corrosion-resistant cylinder designed for precision linear motion in confined spaces. Features stainless steel construction for chemical resistance and vacuum compatibility (down to -100kPa). Includes wear-resistant PTFE seals for >2,000km service life. Requires 5μm filtered air with ISO VG32 lubricant recommended.
- Cleanroom equipment actuators (pharmaceutical/medical)
- Semiconductor wafer handling robots
- Precision dosing valves in food processing
- Micro-positioning in optical alignment systems
- Laboratory automation sample handlers
Installation guidelines:
Maximum side load ≤2N. For vertical mounting, use speed controller (ASC-06) to prevent piston slam.
Lubricate through air ports monthly in continuous operation. Avoid angular misalignment >0.5°.
| Property | Property Value |
|---|---|
| sku | MTI10X15SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
