Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X15SU
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X15SU Specifications
- Model: MTI10X15SU
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 15mm (±1mm tolerance)
- Operation: Air pressure to extend, spring return
- Material: Stainless steel (SUS304 barrel, CR-SUS piston rod)
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -20℃ to 150℃ (with high-temp seals)
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber bumper
- Mounting: Standard (no built-in mounts) with optional MIS-6 brackets
- Protection rating: IP67 (standard seals)
- Weight: 92g ±3g (without accessories)
- Dimensions:
- Total length (retracted): 54mm
- Body diameter: Φ20mm
- Rod end thread: M5x0.8 (male)
- Stroke tolerance: +1.0/-0 mm
Ultra-compact corrosion-resistant cylinder designed for precision motion in harsh environments. Features medical-grade surface finish (Ra≤0.8μm) and food-safe lubrication. Requires 5μm filtered dry air. The stainless steel construction enables steam cleaning compatibility and chemical resistance.
- Pharmaceutical capsule filling machines
- Cleanroom wafer handling robots
- Beverage canning line actuators
- Sterilizable medical devices
- Marine equipment controls
- High-humidity textile machinery
Installation note:
For optimal performance, install with 0.5-1mm axial clearance. Use only PTFE-based lubricants.
Maximum side load: 2.5N. Cycle rate ≤5Hz. Pre-charge with 0.02MPa air before full operation.
| Property | Property Value |
|---|---|
| sku | MTI10X15SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
