Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X15U
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X15U Specifications
- Model: MTI10X15U
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 15mm
- Operation: Push operation (air extending)
- Material: Stainless steel (SUS304 barrel/piston rod)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (2 ports)
- Cushioning: Elastic rubber buffer
- Mounting style: Basic non-switch type
- Weight: 68g ±2%
- Dimensions:
- Total length (retracted): 52mm
- Body diameter: Φ16mm
- Stroke tolerance: +1.0mm
- Rod thread: M5x0.8 male
Ultra-compact corrosion-resistant cylinder with precision-ground rod and honed inner tube surface (Ra≤0.4μm). Features double-lip sealing system with NBR seals for leak-proof operation. Includes anti-rotation guide slot (width 5mm) and operates at ≤1.5m/s piston speed. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 purity.
- Cleanroom semiconductor handling robots
- Precision dosage mechanisms in pharmaceutical equipment
- Micro-positioning in optical lens manufacturing
- Sterile environment food packaging actuators
- Miniature valve control in analytical instruments
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Avoid side load exceeding 1.5N. For vertical mounting,
maintain minimum 0.3MPa pressure to overcome spring force.
Not recommended for continuous reciprocation >5Hz.
| Property | Property Value |
|---|---|
| sku | MTI10X15U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
