Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X20SCA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI10X20SCA Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI10X20SCA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 20mm (±1mm)
- Material: Stainless steel (SUS304 barrel, CR-SUS piston rod)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Rubber pad buffer
- Mounting type: Basic non-switch type
- Weight: 0.12kg ±2%
- Dimensions: 72mm(L) × 28mm(W) × 28mm(H) (retracted state)
- Rod thread: M5x0.8 internal thread
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Do NOT relubricate)
Ultra-compact corrosion-resistant cylinder with full stainless steel construction, designed for precision linear motion in confined spaces. Features double-port design for flexible piping and maintenance-free operation. Ideal for clean environments requiring frequent sterilization or chemical exposure.
- Medical device actuation (IV pumps, dental chairs)
- Food processing equipment valves
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing machines
- Micro-positioning in optical alignment systems
Operational note:
Maintain ≤70% duty cycle for continuous operation. Use clean dry air
with 5-40μm filter. Avoid side loads exceeding 2N. For vertical mounting,
add external stopper for overhung loads.
| Property | Property Value |
|---|---|
| sku | MTI10X20SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
