Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X20SU
$19.97
Regular price
$27.47
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MTI10X20SU
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standard (Φ8-25mm);
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
Installation note:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, reduce payload by 30% to compensate for spring force.
Use anti-vibration nuts for high-cycle applications (>1 million cycles).
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X20SU Specifications
- Model: MTI10X20SU
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 20mm
- Material: Stainless steel (SUS304 body, SUS303 piston rod)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 150℃
- Cushioning: Rubber buffer
- Port size: M5x0.8 (standard), optional NPT1/8
- Seal material: NBR/FKM (optional)
- Weight: 72g ±2g
- Dimensions: 50mm(L) × 28mm(W) × 28mm(H) (excluding rod)
- Rod thread: M4x0.7 external thread
- Mounting: Basic type (no built-in mounts)
- Protection rating: IP65 (standard sealing)
- Lubrication: Pre-lubricated (use ISO VG32 pneumatic oil)
Corrosion-resistant mini cylinder with precision-ground rod for smooth operation in harsh environments. Features non-rotating piston design and dual-purpose mounting slots. Requires 5μm filtered air with 40% relative humidity max. Max piston speed: 500mm/s.
Typical Applications:
- Cleanroom automation equipment
- Food processing machinery (FDA-compliant variants)
- Semiconductor wafer handling systems
- Sterilization chamber actuators
- Marine environment control systems
Installation note:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, reduce payload by 30% to compensate for spring force.
Use anti-vibration nuts for high-cycle applications (>1 million cycles).
| Property | Property Value |
|---|---|
| sku | MTI10X20SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
