Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X20U
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X20U Specifications
- Model: MTI10X20U
- Type: Single-acting (spring return), compact series
- Bore size: 10mm
- Stroke: 20mm (±1mm standard)
- Operating pressure: 0.05–0.7 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Material: Stainless steel (SUS304) barrel & end caps
- Seal material: Heat-resistant NBR (-20℃~100℃)
- Port size: M5x0.8 (standard), optional Rc1/8
- Mounting style: Basic non-switch type with single mounting thread (M5)
- Rod rotation: Free rotation design (±180°)
- Weight: ~98g (without accessories)
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H) (cylinder body only)
- Full length: 70mm (including rod at retracted position)
- ISO standard: Compliant with ISO 6432 mini cylinder specifications
Ultra-compact stainless steel cylinder designed for corrosive environments and precision motion control. Features anti-rust construction and reduced particulate generation, making it ideal for cleanroom applications. The spring-return mechanism ensures fail-safe retraction. Requires 25μm filtered air with ISO 8573-1:2010 Class 4.3.4 air quality.
- Medical device actuation (IV pumps, surgical tools)
- Food processing equipment (filling/sealing machines)
- Semiconductor wafer handling robots
- Pharmaceutical tablet press automation
- Laboratory analysis instrument positioning
Installation note:
Lubricate piston rod with silicone grease (Molykote 111 recommended) monthly in high-cycle applications.
Avoid side load exceeding 2N. For vertical mounting, use rod-down orientation to prevent condensation accumulation.
| Property | Property Value |
|---|---|
| sku | MTI10X20U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
