Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X25CA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X25CA Specifications
- Model: MTI10X25CA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 25mm (±1mm tolerance)
- Operation: Push type (pneumatic extension)
- Material: SUS303 stainless steel body, NBR seals
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5×0.8 (UNF 1/8 optional)
- Cushion type: Adjustable rubber bumper
- Mounting style: Basic non-magnetic base
- Weight: 98g ±2g
- Dimensions:
- Length: 76mm (full extension)
- Width: 22mm (max flange width)
- Height: 22mm (square body profile)
- Corrosion resistance: Passes 96hr salt spray test
- Lubrication: Pre-lubricated (do not relubricate)
Ultra-compact stainless steel cylinder designed for precision motion control in corrosive/clean environments. Features magnetic piston for sensor compatibility and non-sparking construction. The chrome-plated piston rod ensures smooth operation with ≤0.15mm radial play. Requires 5μm filtered dry air.
- Food processing equipment actuators
- Pharmaceutical tablet press mechanisms
- Semiconductor wafer handling robots
- Cleanroom conveyor systems
- Medical sterilization device clamps
Installation guidelines:
Maximum side load ≤2N. Use M3×0.5 mounting screws with 0.6Nm torque limit.
For vertical mounting, position spring end downward. Cycle rate ≤5Hz.
| Property | Property Value |
|---|---|
| sku | MTI10X25CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
