Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X25U
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X25U Specifications
- Model: MTI10X25U
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 25mm
- Material: Stainless steel body (SUS304) + aluminum alloy end caps
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (push-in fitting)
- Mounting type: Standard NAMUR pattern with 2x ø4.5mm mounting holes
- Cushioning: Adjustable rubber buffer
- Weight: 0.12kg
- Dimensions: 54mm (Length) × 20mm (Width) × 20mm (Height) (Cylinder body only, excluding rod extension)
- Rod thread: M5x0.8 external thread at piston end
- Max theoretical force: 55N at 0.7MPa
- Spring force: 6.5N (return stroke)
- Protection rating: IP65
Ultra-compact corrosion-resistant cylinder designed for precision linear motion in confined spaces. Features stainless steel construction for chemical resistance and washdown environments. Spring-return mechanism ensures fail-safe retraction with ≤0.1mm repeat positioning accuracy. Requires 5μm filtered air and ISO VG32 turbine oil lubrication (optional oil-free operation).
- Medical device actuation mechanisms
- Food processing equipment clamping
- Semiconductor wafer handling robots
- Optical lens positioning systems
- Laboratory sample tray indexing
Installation note:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, reduce operating pressure by 20% to compensate
for spring force. Lubricate every 500,000 cycles in normal operation.
| Property | Property Value |
|---|---|
| sku | MTI10X25U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
