Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X30SU
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Miniature Cylinder MTI10X30SU Specifications
- Model: MTI10X30SU
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 30mm
- Material: Stainless steel body (SUS304) + Aluminum alloy end caps
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Port size: M5x0.8 (dual ports)
- Rod thread: M5x0.8 external thread
- Weight: 180g ±5g
- Dimensions:
- Length: 85mm (fully extended)
- Body diameter: 20mm
- Mounting bracket width: 32mm
- Seal material: Fluororubber (FKM) for high temperature resistance
- ISO standard: Compliant with ISO 6432 miniature cylinder specifications
Ultra-compact stainless steel cylinder engineered for corrosive environments and precision motion control. Features anti-rotation rod design and IP67 protection rating, with optional magnetic piston for position sensing. Requires 5μm filtered air and recommends ISO VG32 hydraulic oil mist lubrication (0.1-0.3cc/min).
- Pharmaceutical cleanroom equipment
- Semiconductor wafer handling robots
- Food processing machinery (NSF compliant)
- High-cycle automation: 1.5 million cycles guaranteed
- Precision clamping in CNC tool changers
Installation note:
Mount using M4 screws (max torque 1.2N·m). For vertical installations,
maintain ≥3mm clearance below cylinder for spring decompression.
Lubricate through air supply for optimal seal life (non-lube operation reduces lifespan by 40%).
| Property | Property Value |
|---|---|
| sku | MTI10X30SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
