Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X30U
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI10X30U Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI10X30U
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Operating temperature: -20℃ to 80℃
- Port thread: M5×0.8 (standard) or G1/8 optional
- Cushioning: Fixed rubber buffer
- Material: Stainless steel (SUS304 barrel, CRMo steel piston rod)
- Seal material: NBR with grease retention design
- Rod end: Female thread M5×0.8
- Weight: 98g ±2g
- Dimensions:
- Extended length: 75mm
- Retracted length: 45mm
- Body diameter: 20mm
- Mounting bracket width: 32mm
- ISO standard: 6431 (compact series)
- Protection rating: IP67 (standard seals)
Ultra-compact corrosion-resistant cylinder with space-saving design, featuring a polished stainless steel barrel for smooth operation in clean environments. The spring-return mechanism provides reliable retraction force up to 3.2N (at 0.5MPa). Includes built-in auto-adjusting cushioning to minimize end-impact noise below 65dB.
- Medical device actuation (sterilization-friendly construction)
- Semiconductor wafer handling robots
- Food packaging machinery (FDA-compliant grease options)
- Precision optical lens positioning systems
- Laboratory automation with limited mounting space
Installation guidelines:
Use anti-rotation brackets (optional accessory) for precise linear motion.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃.
Maximum side load capacity: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | MTI10X30U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
