Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X40CA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X40CA Specifications
- Model: MTI10X40CA
- Action type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 40mm (±1mm tolerance)
- Material: Stainless steel (SUS304 barrel/piston rod)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 150℃
- Cushioning: Rubber buffer (adjustable end caps)
- Port size: M5x0.8 (standard UNF thread)
- Mounting type: Basic non-magnetic base (optional accessories available)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Rod end type: Female thread M5x0.8
- Max speed: 500mm/s (with cushioning)
- Weight: 180g ±5g (including fittings)
- Dimensions: 84mm(L) × 20mm(W) × 20mm(H) (full extension length)
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km)
Ultra-compact stainless steel cylinder with chemical-resistant construction, featuring precision-ground rod and hard chrome plating on critical wear surfaces. The spring-return design ensures fail-safe retraction, while the non-magnetic base prevents interference in sensitive applications. Requires 5μm filtered dry air (non-lubricated operation compatible).
- Cleanroom automation in semiconductor manufacturing
- Food processing equipment (FDA-compliant design)
- Medical device actuation systems
- High-temperature oven door mechanisms
- Corrosive environment positioning devices
- Precision dispensing machines
Installation note:
Mount using included anti-vibration washers. For vertical installations,
position rod end downward to prevent moisture accumulation.
Maximum side load: 3N. Annual inspection recommended for spring tension.
| Property | Property Value |
|---|---|
| sku | MTI10X40CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
