Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X40SCA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI10X40SCA Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI10X40SCA
- Type: Single-acting spring return (miniature)
- Bore size: 10mm
- Stroke: 40mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Material: Stainless steel cylinder tube (SUS304)
- Seal material: NBR + PU hybrid seals
- Port size: M5x0.8 (1/8" NPT optional)
- Piston rod material: Stainless steel (SUS420)
- Weight: ~210g (excluding accessories)
- Dimensions: 40mm(W) × 40mm(D) × 80mm(H) (at retracted position)
- Max theoretical thrust: 62.8N at 0.8MPa
- Response time: ≤0.5s (at 0.5MPa)
- Lubrication: Pre-lubricated (grease-packed)
- ISO standard: 6432 compliant
Ultra-compact stainless steel cylinder designed for corrosive environments and precision motion control. Features hybrid sealing system for extended service life (up to 3,000km travel distance). Includes anti-rotation guide slots for precise linear motion. Suitable for vertical/horizontal mounting with IP67 protection rating.
- Semiconductor wafer handling robots
- Medical device actuation systems
- Food processing equipment (NSF compliant)
- Cleanroom automation (ISO Class 5-8)
- Optical lens positioning mechanisms
- Laboratory analytical instruments
Installation note:
Requires 5μm filtered dry air supply. For vertical downward mounting,
reduce load capacity by 30%. Perform monthly lubrication checks in
high-cycle applications (>500 cycles/min). Avoid side load exceeding
0.5N·m during installation.
| Property | Property Value |
|---|---|
| sku | MTI10X40SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
