Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X50CA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI10X50CA Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI10X50CA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 50mm
- Operating pressure: 0.05–0.7 MPa
- Operating medium: Clean dry air (40μm filtration required)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Port thread: M5×0.8
- Cushioning: Adjustable rubber buffer
- Material: Stainless steel body (SUS304), NBR seals
- Protection rating: IP40
- Weight: 180g ±5g
- Dimensions:
- Body length: 72mm
- Total extended length: 122mm
- Mounting base: 20mm × 20mm
- Rod end thread: M4
- Compliance: ISO 6432 standard
Ultra-compact stainless steel cylinder designed for corrosive environments and precision motion control. Features self-lubricating guide bushings and anti-rotation rod design, optimized for vertical/horizontal mounting in confined spaces. Requires minimal maintenance with 1,500km service life under standard conditions.
- Semiconductor wafer handling robots
- Cleanroom automation equipment
- Medical device assembly lines
- Food processing machinery (NSF compliant)
- Precision clamping fixtures
Installation guidelines:
Use locknuts (M5) with 0.8–1.2Nm torque for port connections.
For horizontal mounting, add support rail to prevent sagging.
Lubricate every 3 months with ISO VG32 hydraulic oil in high-cycle applications.
- MTI-MB: Front flange mounting bracket
- MTI-SS: Stainless steel magnetic sensor (PNP/NPN)
- MTI-AS: Anti-vibration rod end (silicon coating)
| Property | Property Value |
|---|---|
| sku | MTI10X50CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <50mm> |
