Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X5U
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X5U Specifications
- Model: MTI10X5U
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 5mm
- Operating pressure: 0.05–0.7 MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Cylinder material: SUS304 stainless steel
- Rod material: SUS303 stainless steel
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 100℃
- Cushioning: Rubber buffer (both ends)
- Mounting type: Standard axial mounting holes (2xM3 threaded)
- Weight: 85g ±2%
- Dimensions: 56mm(L) × 20mm(W) × 20mm(H) (retracted position)
- Extended length: 61mm (full stroke)
- Repeat accuracy: ±0.1mm
- Max piston speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation possible)
Ultra-compact corrosion-resistant cylinder designed for precision motion in confined spaces. Features full stainless steel construction with hybrid seals for chemical resistance. The MTI series delivers 0.98N thrust at 0.5MPa pressure. Requires 5μm filtered dry air (non-lubricated) or oil-mist lubrication (optional).
- Cleanroom medical device actuators
- Semiconductor wafer handling robots
- Food packaging machinery (NSF compliant)
- Precision dosing valve controls
- Laboratory automation positioning
- 3D printer component actuation
Installation note:
For optimal performance, maintain ≤0.5mm alignment tolerance during mounting.
Use copper-free anti-seize compound on stainless steel threads. Cycle 3-5 times
at 0.3MPa before full-pressure operation to seat seals.
| Property | Property Value |
|---|---|
| sku | MTI10X5U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
