Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI12X10CA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI12X10CA Specifications
- Model: MTI12X10CA
- Type: Single-acting (spring return)
- Bore size: 12mm
- Stroke: 10mm
- Operation: Air pressure extension with mechanical spring retraction
- Cylinder material: Stainless steel (SUS304)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR rubber (FKM optional)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Port size: M5x0.8 (1/8" NPT optional)
- Cushion type: Adjustable rubber buffer
- Mounting style: Basic type (accessory brackets available)
- Weight: 0.08kg ±3%
- Dimensions (L×W×H):
- Retracted length: 52mm
- Extended length: 62mm
- Body diameter: 20mm
- Mounting hole spacing: 25mm (standard pattern)
- ISO standard: 6432 compliant
- Corrosion resistance: IP67 rating (dust/water resistant)
Ultra-compact stainless steel cylinder engineered for precision linear motion in corrosive or washdown environments. Features a space-saving design with 90% smaller footprint than standard ISO cylinders. The full-metal construction ensures durability in high-cycle applications (up to 1 million cycles). Includes anti-rotation guide for stable operation. Requires 5μm filtered air with ISO VG32 lubricant recommended.
- Food processing machinery (FDA-compliant version available)
- Medical device actuation systems
- Semiconductor wafer handling robots
- Cleanroom automation equipment
- Chemical dispensing valve controls
Installation tip:
For vertical mounting, position spring-end downward to prevent piston rod sagging.
Maximum side load capacity: 2.5N at full extension. Lubricate every 500km of cumulative stroke travel.
| Property | Property Value |
|---|---|
| sku | MTI12X10CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
