Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI12X10SCA
$23.23
Regular price
$30.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MTI12X10SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standard (Φ8-25mm);
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
Installation note:
Use PTFE-based lubricant on rod before initial operation.
Maintain ≤0.05mm alignment tolerance during mounting.
For vertical mounting, position piston rod downward to prevent debris accumulation.
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI12X10SCA Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI12X10SCA
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 10mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 150℃
- Port thread: M5×0.8
- Mounting style: Basic front flange (NFI standard)
- Body material: SUS304 stainless steel
- Piston rod material: SUS303 stainless steel
- Seal material: Fluororubber (FKM)
- Cushion type: Adjustable rubber cushion
- Max. theoretical speed: 500 mm/s
- Weight: 0.15 kg (without accessories)
- Dimensions:
- Total length (L): 52mm (stroke 10mm + body length)
- Cylinder diameter (W): 24mm
- Height with rod (H): 32mm
Ultra-compact corrosion-resistant cylinder with precision-ground rod and IP67 protection rating. Features double-sealed construction for vacuum/pressure applications (0.1kPa–0.9MPa). Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (1:30 ratio recommended).
Typical Applications:
- Medical device actuation systems (autoclave-safe)
- Food processing equipment in washdown environments
- Semiconductor wafer handling robots
- Precision optical lens positioning mechanisms
- Cleanroom automation with frequent sterilization
Installation note:
Use PTFE-based lubricant on rod before initial operation.
Maintain ≤0.05mm alignment tolerance during mounting.
For vertical mounting, position piston rod downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | MTI12X10SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
