Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI12X10SU
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI12X10SU Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MTI12X10SU
- Action type: Single-acting (spring return)
- Bore size: 12mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 150℃
- Port size: M5x0.8 (standard) with UNF/PT/NPT adapters available
- Cushioning: Adjustable rubber buffer
- Body material: SUS304 stainless steel
- Rod material: SUS303 stainless steel
- Seal material: NBR (standard)/FKM (optional)
- Mounting type: Basic rod-end threaded (M5x0.8)
- Weight: 0.12kg (without accessories)
- Dimensions:
- Total length (retracted): 52mm
- Body diameter: 20mm
- Rod end thread length: 6mm
- Lubrication: Pre-lubricated (Grease G-30)
- Corrosion resistance: Passes 48hr salt spray test
Ultra-compact stainless steel cylinder with oxidation-resistant construction, designed for corrosive environments and cleanroom applications. Features a space-saving 20mm diameter body with precision-ground rod for smooth operation. The spring-return mechanism provides reliable position recovery even during pressure loss. Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Food processing machinery actuators
- Pharmaceutical packaging line controls
- Semiconductor wafer handling robots
- Marine equipment pneumatic systems
- Sterilization chamber door mechanisms
Installation note:
Maximum side load 3N·m. For vertical mounting, use rod-end down orientation.
Apply thread lock (Loctite 243 recommended) on mounting screws. Perform monthly
lubrication checks in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | MTI12X10SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
