Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI12X10U
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI12X10U Specifications
- Model: MTI12X10U
- Type: Single-acting (spring return)
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.05–0.7 MPa
- Max thrust: 43N @0.5MPa
- Port size: M5x0.8 (UNF 1/8" optional)
- Cushioning: Adjustable rubber buffer
- Material: Stainless steel (SUS304 barrel)
- Seal material: NBR + Fluororubber (FKM) hybrid
- Temperature range: -20℃ to 150℃
- Weight: 0.22kg
- Dimensions: 58mm(L) × 20mm(W) × 20mm(H) (fully retracted)
- Rod end thread: M4x0.7
- Lubrication: Pre-lubed (VG68 oil), maintenance-free
- ISO standard: 6432 compliant
Ultra-compact corrosion-resistant cylinder with precision-ground rod, optimized for high-cycle operations in constrained spaces. Features double-sealed construction with IP67 protection rating. Requires 40μm filtered air and operates best with 1-3 m/s piston speed. Includes anti-rotation guide slots for stable linear motion.
- Semiconductor wafer handling robots
- Medical device actuation mechanisms
- Food processing equipment (NSF compliant)
- Precision optical lens positioning
- Laboratory automation sample handlers
- Cleanroom environment systems
Installation note:
Mount using alignment jigs to prevent side load. For vertical installations,
maintain ≥0.3MPa pressure to overcome spring force. Apply Loctite 243
to mounting screws (2.5N·m max torque).
| Property | Property Value |
|---|---|
| sku | MTI12X10U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
