Airtac MU Mini Free Mount Cylinder MU10X10B
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X10B Technical Details
- Model: MU10X10B
- Type: Single-acting spring return (Push type)
- Bore size: Ø10mm
- Stroke: 10mm
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Port thread: M5×0.8
- Tube material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 118g ±2%
- Dimensions: 60mm(L) × 20mm(W) × 20mm(H) (excluding mounting accessories)
- Mounting options: Side/end plate mounting with optional brackets (MA/MB series)
- ISO standard: Compliant with ISO 6432 (8mm variant adaptation)
Ultra-compact cylinder optimized for space-critical automation systems, featuring a 0.5μm surface roughness precision rod for smooth operation. The dual-purpose mounting grooves enable 180° orientation flexibility. Includes built-in auto-adjusting cushioning that reduces impact noise by 15dB compared to standard models.
- Semiconductor wafer handling robots
- Micro-dosing valves in pharmaceutical filling machines
- Precision lens positioning in optical manufacturing
- PCB test fixture ejection mechanisms
- 3D printer nozzle cleaning systems
Installation protocol:
Maximum lateral load ≤0.3N·m. Lubricate through air port (VG32 oil recommended)
every 50km stroke operation. Avoid direct coolant exposure - use protective
sleeve (ASF-10 accessory) in machining environments.
| Property | Property Value |
|---|---|
| sku | MU10X10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
