Airtac MU Mini Free Mount Cylinder MU10X10S
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU10X10S Miniature Free Mount Cylinder Specifications
- Model: MU10X10S
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 10mm
- Operating pressure: 0.05–0.7 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Mounting style: Direct mounting with 2x M3 threaded holes
- Port size: M5x0.8 (standard)
- Material: Aluminum alloy body, stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.12kg ±2%
- Dimensions (L×W×H):
- Basic length: 55mm (excluding rod)
- Full extended length: 65mm
- Body width: 20mm
- Height (with mounting): 25mm
- Protection rating: IP40
- Lubrication: Pre-lubricated (maintenance-free for 2000km operation)
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features a unique anti-rotation guide structure ensuring precise linear motion. The anodized surface treatment provides corrosion resistance in humid environments. Compatible with ISO 6432 mounting accessories.
- PCB handling robots in electronics assembly
- Micro-dosing valves in medical devices
- Precision lens positioning systems
- Laboratory sample sorting mechanisms
- Compact packaging machine actuators
Installation note:
For optimal performance, maintain 0.3-0.5mm clearance between mounting surface and cylinder base.
Use M3 screws with maximum torque of 0.6N·m. Lubricate piston rod monthly in high-cycle applications (>500 cycles/min).
Do NOT use silicone-based lubricants.
Minimum operating pressure must exceed 0.05MPa to overcome spring force (0.4N initial resistance).
| Property | Property Value |
|---|---|
| sku | MU10X10S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
