Airtac MU Mini Free Mount Cylinder MU10X10SB
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X10SB Technical Details
- Model: MU10X10SB
- Bore size: 10mm
- Stroke: 10mm
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Cushioning: Rubber buffer (both ends)
- Port thread: M5x0.8
- Rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (hard anodized)
- Seal type: NBR wear-resistant seals
- Weight: 48g ±2g
- Dimensions:
- Body length: 51mm
- Overall length (extended): 61mm
- Mounting base: 20mm(W) × 12mm(H)
- Rod diameter: 4mm
Ultra-compact cylinder designed for space-constrained automation systems, featuring a unique "free mount" design that allows direct installation without separate brackets. The double-acting operation provides precise linear motion control, while the hardened aluminum construction ensures durability in high-cycle applications (up to 15 million cycles). Includes built-in auto-switch grooves for sensor compatibility.
- PCB handling robots in electronics assembly
- Precision dosing mechanisms in medical devices
- Compact clamping fixtures for CNC tooling
- Paper feed mechanisms in office automation
- Miniature sorting gates in packaging lines
Installation guidance:
For optimal performance, maintain 0.5mm clearance between cylinder body and mounting surface.
Use thread-locking compound on mounting screws (recommended torque: 0.3N·m). Lubricate with ISO VG32
hydraulic oil if operating in dry conditions.
| Property | Property Value |
|---|---|
| sku | MU10X10SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
