Airtac MU Mini Free Mount Cylinder MU10X15
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X15 Technical Details
- Model: MU10X15
- Bore size: Ø10mm (0.39")
- Stroke: 15mm (0.59")
- Operating pressure: 0.05–0.9 MPa (7–130 PSI)
- Max thrust: 7.1kgf @ 0.63MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (standard) with Rc1/8/NPT1/8 adapters optional
- Cushioning: Rubber buffer (both ends)
- Piston speed: 50–700mm/s
- Mounting type: Free installation (no dedicated bracket required)
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.12kg (0.26lbs)
- Dimensions:
- Body diameter: 20mm (0.79")
- Total length (retracted): 50mm (1.97")
- Extended length: 65mm (2.56")
- Port spacing: 12mm (0.47") center-to-center
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features anti-rotation piston rod design and dual-action operation with 360° adjustable mounting flexibility. The corrosion-resistant construction enables use in humid environments (non-washdown). Requires 5μm filtered air with ISO VG32 turbine oil lubrication (optional oil-free operation).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms for CNC tooling
- Medical device positioning systems
- Textile machinery thread control
- Laboratory automation sample handlers
- Packaging machine micro-actuation
Installation tip:
Maintain 0.5mm minimum clearance between cylinder body and mounting surface for thermal expansion.
Use Loctite 243 (medium strength) on mounting screws. Lubricate through air port using ISO VG32 oil mist
(1 drop/1,000 cycles) if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | MU10X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
