Airtac MU Mini Free Mount Cylinder MU10X15SB
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X15SB Specifications
- Model: MU10X15SB
- Bore size: 10mm
- Stroke: 15mm
- Action type: Double-acting
- Operating pressure: 0.05-0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber cushion (both ends)
- Port size: M5×0.8 (standard)
- Piston speed: 50-700 mm/s
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (standard), optional FKM
- Weight: 0.11 kg
- Dimensions (L×W×H):
- Retracted length: 72mm
- Extended length: 87mm
- Body width: 20mm
- Mounting height: 25mm
The MU10X15SB features a compact profile with 0.5μm surface roughness precision, offering smooth operation in confined spaces. Its integrated mounting grooves enable direct installation without brackets. The cylinder incorporates wear-resistant guide rings and features IP54 protection against particulate ingress.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms in micro-molding machines
- Valve actuation in portable medical analyzers
- Component ejection in SMT pick-and-place systems
- Door interlock systems for cleanroom equipment
Installation note:
Optimal performance achieved when mounted horizontally. Lubricate through air port (ISO VG32)
for initial use. Allow 0.5mm clearance between cylinder body and mounting surface for thermal expansion.
- Mounting brackets: MFH-10 series
- Rod ends: M-EN10 (female thread)
- Magnetic sensors: D-A73 (non-contact type)
| Property | Property Value |
|---|---|
| sku | MU10X15SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
