Airtac MU Mini Free Mount Cylinder MU10X20
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X20 Technical Details
- Model: MU10X20
- Type: Single-acting spring return (normally closed)
- Bore size: 10mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Cushioning: Rubber buffer (both ends)
- Mounting style: Free installation (no fixed brackets)
- Port size: M5x0.8 (dual ports)
- Piston rod thread: M4x0.7
- Material: Aluminum alloy barrel/stainless steel rod
- Weight: 0.12kg (excluding accessories)
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H) (barrel only)
- Full extended length: 70mm (barrel + stroke)
- Lubrication: Pre-lubricated (maintenance-free for 2000km)
- Protection rating: IP40 (standard)/IP67 (optional wiper)
Ultra-compact cylinder optimized for space-constrained automation systems. Features dual anti-rotation design for precise linear motion control. The anodized barrel resists corrosion in humid environments, while the chrome-plated piston rod ensures smooth operation. Requires 5μm filtered compressed air with ISO VG32 lubricant (optional).
- PCB handling robots in electronics assembly
- Dispenser valve actuation in medical devices
- Label peeling mechanisms in packaging lines
- Precision clamping in optical lens production
- Vending machine currency acceptors
Installation tip:
Maximum lateral load 3N. For vertical mounting, reduce operating pressure by 20%.
Use locknuts (M4) with 0.3-0.5Nm torque for rod-end accessories. Avoid side loads exceeding 0.5mm misalignment.
| Property | Property Value |
|---|---|
| sku | MU10X20 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
