Airtac MU Mini Free Mount Cylinder MU10X20B
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X20B Specifications
- Model: MU10X20B
- Type: Single-acting spring return (free mount design)
- Bore size: 10mm
- Stroke: 20mm ±0.5mm
- Operating pressure: 0.15–0.8 MPa
- Port thread: Dual M5x0.8 (G1/8 optional)
- Piston speed: 50–700 mm/s (lubricated)
- Ambient temperature: -20℃ to 80℃
- Buffer type: Rubber cushion (adjustable)
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.12kg ±3%
- Dimensions (L×W×H): 60mm × 30mm × 30mm (compact section design)
- Protection rating: IP54 (standard)
- Mounting options: Side tapped holes (M4×0.7×5mm deep)
Ultra-compact cylinder optimized for space-constrained automation systems, featuring a unique anti-rotation guide structure for precise linear motion. The hard-anodized barrel provides exceptional wear resistance, while the chrome-plated piston rod ensures corrosion protection. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- PCB handling robots in electronics manufacturing
- Dispenser nozzle actuation in medical devices
- Precision clamping mechanisms for optical lens production
- Compact sorting gates in logistics automation
- Veterinary equipment sterilization door controls
Installation note:
Maximum allowable lateral load: 2.5N. For vertical mounting,
use auxiliary guide mechanisms when handling payloads over 0.8kg.
Lubricate through air port (2-3 drops ISO VG32 oil) every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | MU10X20B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
