Airtac MU Mini Free Mount Cylinder MU10X20S
$26.27
Regular price
$33.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MU10X20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The MU Series Compact Free Mount Cylinder (JIS Standard Compliant) offers advanced engineering solutions:
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
Installation guidelines:
Maintain 0.5-1mm clearance around cylinder body for thermal expansion.
Use torque-controlled tightening (0.8-1.2N·m) on mounting screws.
For vertical installations, position rod end downward to prevent dust accumulation.
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X20S Specifications
- Model: MU10X20S
- Type: Single-acting spring return (push type)
- Bore size: 10mm (±0.1mm tolerance)
- Stroke: 20mm (adjustable ±1mm)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Rubber buffer (both ends)
- Mounting style: Free installation (non-guided)
- Port size: M5×0.8 (Rc1/8 optional)
- Piston rod thread: M5×0.8 external thread
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR with graphite coating
- Weight: 0.12kg (excluding accessories)
- Dimensions:
- Total length: 50mm (at full retraction)
- Body width: 20mm
- Height with rod: 35mm
- Mounting hole spacing: 15mm center-to-center
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact cylinder optimized for space-constrained automation systems. Features anti-rotation design for stable linear motion and corrosion-resistant construction. The double-sealed piston ensures leak-free operation even in high-cycle applications (up to 1.5 million cycles). Compatible with ISO 6432 mounting accessories.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Precision valve actuation in analytical instruments
- Medical device component positioning
- Packaging machine clamp mechanisms
- Semiconductor wafer processing equipment
Installation guidelines:
Maintain 0.5-1mm clearance around cylinder body for thermal expansion.
Use torque-controlled tightening (0.8-1.2N·m) on mounting screws.
For vertical installations, position rod end downward to prevent dust accumulation.
Operation notes:
- Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2
- Re-lubrication interval: 500,000 cycles (using ISO VG32 hydraulic oil)
- Max side load: 2.5N at rod end
| Property | Property Value |
|---|---|
| sku | MU10X20S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
