Airtac MU Mini Free Mount Cylinder MU10X20SB
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X20SB Specifications
- Model: MU10X20SB
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 20mm (±1mm)
- Operating pressure: 0.05–0.7 MPa
- Operating temperature: -10℃ to 70℃
- Port size: M5×0.8 (standard dual ports)
- Cushioning: Adjustable rubber buffer
- Piston rod thread: M5×0.8 (external thread)
- Material:
- Cylinder tube: Aluminum alloy oxidation
- Piston rod: Stainless steel (SUS304)
- Seals: NBR + PU combination
- Mounting style: Standard non-switch base (side mounting holes)
- Weight: 42g ±2g
- Dimensions:
- Length: 69mm (full retracted)
- Width: 20mm (body diameter)
- Height: 20mm (excluding rod)
- Protection class: IP54 (standard sealing)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features dual anti-rotation design for stable linear motion and corrosion-resistant construction. The integrated guide slots enable flexible mounting orientations (horizontal/vertical). Requires 5μm filtered lubricated air for optimal performance.
- PCB board clamping in electronics assembly
- Micro-part ejection in SMT machines
- Valve actuation in portable medical devices
- Precision positioning in semiconductor handling
- Miniature gripper mechanisms in robotics
Installation tip:
Apply thread locker (Loctite 243 recommended) on mounting screws when used in high-vibration environments.
Maximum side load capacity: 2.5N at full extension.
| Property | Property Value |
|---|---|
| sku | MU10X20SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
