Airtac MU Mini Free Mount Cylinder MU10X25
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X25 Specifications
- Model: MU10X25
- Bore diameter: 10 mm
- Stroke: 25 mm (±1.5 mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Rod thread: M5×0.8 external thread
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR/PU hybrid seals
- Temperature range: -10℃ to 70℃
- Mounting style: Axial 2-point (standard), optional side/face mounts
- Weight: 0.12 kg (bare cylinder), 0.15 kg with accessories
- Dimensions: 80mm(L) × 20mm(W) × 20mm(H) (retracted position)
- Max speed: 500 mm/s (with cushion adjustment)
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
Ultra-compact cylinder optimized for space-constrained automation systems. Features dual anti-rotation design for precise linear motion and integrated mounting slots for tool-free installation. Compatible with ISO 6432 mounting accessories. Requires 5μm filtered air with ≤40% relative oil mist content.
- PCB handling robots in electronics assembly
- Micro-dosing valves in medical analyzers
- Precision clamping in watchmaking jigs
- Paper feed mechanisms in compact printers
- Lens positioning in optical equipment
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, reduce operating pressure by 20% to compensate for self-weight drift.
Relubricate every 500km of cumulative stroke movement.
| Property | Property Value |
|---|---|
| sku | MU10X25 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
