Airtac MU Mini Free Mount Cylinder MU10X25S
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Cylinder MU10X25S Technical Specifications
- Model: MU10X25S
- Bore size: 10mm (0.39")
- Stroke: 25mm (0.98")
- Operation type: Single-acting (spring return)
- Working pressure: 0.05-0.7 MPa (7-101.5 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable rubber buffer
- Piston rod thread: M5×0.8 (external)
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Weight: 68g (2.4oz)
- Dimensions:
- Body length: 56mm (2.20")
- Extended length: 81mm (3.19")
- Width: 20mm (0.79")
- Height: 20mm (0.79")
- Mounting: Non-rotating rod with 2x M3 threaded mounting holes
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact cylinder designed for space-constrained automation systems. Features anodized aluminum construction with chrome-plated piston rod for corrosion resistance. The spring-return mechanism ensures fail-safe retraction, while the non-rotating rod design maintains precise linear motion alignment. Compatible with ISO 6432 mounting accessories.
- PCB handling robots in electronics manufacturing
- Precision valve actuation in analytical instruments
- Medical device component positioning
- Semiconductor wafer processing equipment
- Compact gripper mechanisms in packaging lines
Installation guidelines:
Maximum side load ≤1.5N. For vertical mounting, use spring-side down configuration.
Maintain 0.5mm minimum clearance between rod end and mechanical stops. Lubricate with
ISO VG32 turbine oil if operated continuously above 60℃.
| Property | Property Value |
|---|---|
| sku | MU10X25S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
