Airtac MU Mini Free Mount Cylinder MU10X30
$23.95
Regular price
$31.45
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MU10X30
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The MU Series Compact Free Mount Cylinder (JIS Standard Compliant) offers advanced engineering solutions:
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
Installation tip:
For vertical mounting applications exceeding 0.5m/s piston speed,
use external shock absorbers. Maintain 0.5mm minimum clearance
between rod end and load during alignment.
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Compact Cylinder MU10X30 Technical Details
- Model: MU10X30
- Bore size: 10mm (0.39")
- Stroke: 30mm (1.18")
- Action type: Double-acting
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Port thread: M5×0.8 (standard) / PT1/8 optional
- Cushioning: Rubber buffer (both ends)
- Piston rod material: Stainless steel SUS304
- Cylinder tube: Anodized aluminum alloy
- Seal material: Nitrile rubber (NBR)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 0.12kg (4.23oz)
- Dimensions: 80mm(L) × 20mm(W) × 20mm(H)
- Mounting: Free position (non-rotating rod)
- Rod end: Male M5 thread
- ISO standard: 6432 (compact cylinder specification)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features corrosion-resistant construction with precision honed bore and low-friction seals. Requires 40μm filtered dry air with ISO VG32 lubricator oil (optional oil-free operation available).
Typical Applications:
- PCB handling robots in electronics manufacturing
- Medical device actuation mechanisms
- Automated test equipment positioners
- Semiconductor wafer processing tools
- Compact packaging machine ejectors
Installation tip:
For vertical mounting applications exceeding 0.5m/s piston speed,
use external shock absorbers. Maintain 0.5mm minimum clearance
between rod end and load during alignment.
Cycle Life:
5,000km travel distance (NBR seals) / 8,000km (optional PU seals)
under standard operating conditions (0.5MPa, 20℃, clean air)
| Property | Property Value |
|---|---|
| sku | MU10X30 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
