Airtac MU Mini Free Mount Cylinder MU10X30B
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X30B Technical Details
- Model Code: MU10X30B
- Bore Size: 10mm (0.39") precision honed
- Stroke Length: 30mm (1.18") ±0.5mm tolerance
- Operating Pressure: 0.05-0.9 MPa (7-130 PSI)
- Ambient Temperature: -10℃ to 70℃ (14°F to 158°F)
- Port Thread: M5×0.8 (standard) with optional G1/8 adapters
- Cushioning: Adjustable rubber buffer (both ends)
- Piston Material: Hard anodized aluminum alloy
- Rod Material: Chrome-plated steel (HRC 45-50)
- Seal Type: NBR+PU hybrid seals (oil-resistant)
- Weight: 98g ±2g (without accessories)
- Dimensions: 70mm(L) × 40mm(W) × 40mm(H) (2.76" × 1.57" × 1.57")
- Repeat Accuracy: ±0.1mm
- Max Speed: 500mm/s (with cushioning engaged)
- Mounting: Universal 4-hole pattern with M4 threads
Ultra-compact pneumatic cylinder featuring space-saving cube design and 360° adjustable mounting capability. The dual-cushion structure reduces end-impact noise to <65dB(A). Integrated wear-resistant guide minimizes piston rotation. Pre-lubricated for maintenance-free operation (2 million cycles).
- PCB handling robots - component insertion
- Pharmaceutical blister packaging machines
- Semiconductor wafer sorting equipment
- Automated test jig actuation
- 3D printer nozzle positioning systems
Installation Best Practice:
Use vibration-resistant thread locker on mounting screws. Maintain 0.3-0.6 MPa air pressure for optimal seal life.
For vertical mounting, install exhaust mist separator to prevent lubricant drainage.
| Property | Property Value |
|---|---|
| sku | MU10X30B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
