Airtac MU Mini Free Mount Cylinder MU10X4
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X4 Technical Details
- Model: MU10X4 (MU-10×4-S)
- Bore size: 10mm
- Stroke: 4mm (adjustable cushion)
- Operating pressure: 0.05–0.7 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (dual ports)
- Piston speed: 50–700 mm/s
- Buffer type: Rubber cushion (both ends)
- Mounting style: Free installation (no specific orientation required)
- Rod material: Stainless steel (SUS304)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seals: NBR (nitrile rubber)
- Weight: 0.055 kg (body only)
- Dimensions:
- Extended length: 62mm
- Retracted length: 58mm
- Body diameter: Φ16mm
- Mounting hole spacing: 20mm (center-to-center)
- Protection class: IP40 (standard), IP67 (optional wiper upgrade)
- Lubrication: Pre-lubricated (maintenance-free for 2000km stroke)
Ultra-compact pneumatic cylinder designed for space-constrained automation applications requiring precise linear motion. Features a unique "free mount" design allowing direct installation without brackets through its integrated mounting holes. The double-acting operation provides controlled bidirectional movement with adjustable cushioning for smooth end-of-stroke deceleration.
- PCB board component insertion machines
- Micro-dosing valves in pharmaceutical equipment
- Optical lens positioning systems
- Semiconductor wafer handling arms
- Compact gripper mechanisms in collaborative robots
- Precision paper feed mechanisms in printers
- Use M3 screws (max torque 0.6N·m) for mounting
- Maintain 5mm clearance around cylinder body for heat dissipation
- Install air filter (5μm or finer) upstream
- For vertical installations, use speed controller to prevent piston slam
Maintenance Tip: Inspect rod seals every 500,000 cycles in high-frequency applications. Use only ISO VG32 class hydraulic oil if supplemental lubrication required.
| Property | Property Value |
|---|---|
| sku | MU10X4 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
