Airtac MU Mini Free Mount Cylinder MU10X4B
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mounting Cylinder MU10X4B Specifications
- Model: MU10X4B
- Bore size: 10mm
- Stroke: 4mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable rubber buffer (both ends)
- Port thread size: M5×0.8
- Mounting type: Free mounting (optional foot/base, front flange, rear flange)
- Cylinder tube material: Aluminum alloy (hard anodized)
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 0.05kg ±2%
- Dimensions:
- Total length (L): 50mm (at mid-stroke)
- Body width (W): 20mm
- Height (H): 20mm (excluding mounting accessories)
- Piston rod diameter: 4mm
- Protection class: IP40 (standard), IP67 optional
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if re-lubing required)
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features dual adjustable cushioning for smooth end-of-stroke deceleration and corrosion-resistant construction. The free mounting design allows 360° orientation flexibility with multiple bracket options. Precision honed tube ensures consistent performance over 5,000km service life.
- Semiconductor wafer handling robots
- Medical device actuation mechanisms
- 3C product assembly jigs (mobile phone components)
- Precision valve opening/closing systems
- Laboratory automation positioning stages
Installation note:
Maintain 0.5mm minimum clearance between piston rod and guide mechanisms.
For vertical mounting, use anti-drop locking nuts (optional accessory MD6).
Lubricate every 3 million cycles in high-frequency applications.
Avoid side loads exceeding 2N.
Use rod-end bearings for angular force applications.
Maximum permissible lateral misalignment: ±0.3mm.
| Property | Property Value |
|---|---|
| sku | MU10X4B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
